Antec DP503

$425.00

DP503
Mid-Tower E-ATX Gaming CaseOutstanding Compatible Performance
SKU: e70ce68d4496-1-1-1-2-1-1-1-1-1-1-1-1-1-1-1-1-1-1 Categories: , Tags: ,
Case Specification
Dimensions 483 x 220 x 492 mm (DWH)
Form Factor Mid Tower
Materials Steel, Plastic
Mainboard Support E-ATX, ATX, Micro-ATX, ITX
Front Access & Controls Power, LED control button, USB 3.0 x 2, TYPE-C 3.2 Gen 2 x 1, MIC x 1, HD-AUDIO x 1
Side Panel 4mm Tempered Glass
Drive Bays
Expansion Slots 7
3.5″ / 2.5″ 2 / 2
2.5″ 2
Fan
Front 120mm x 3 / 140mm x 3 / 185mm x 2
Top 120mm x 3 / 140mm x 2
Power Supply Shroud 120mm x 2
Rear 120mm x 1
Included Fan(s) 120mm ARGB fans in front x 3
Radiator Support
Front 120 / 140 / 240 / 280 / 360mm
Top 120 / 140 / 240 / 280 / 360mm
Rear 120mm
Clearance
Max GPU Length ≤ 375mm
Max CPU Cooler Height ≤ 170mm
Max PSU Length ≤ 205mm(with HDD)
≤ 410mm(without HDD)
Cable Routing Space ≤ 23mm
Accessories
Fan & LED Control Hub Yes
GPU Holder Yes
Cable Routing Grommets Yes, 8 pcs
Fixed Cable Ties Yes, 3 pcs
Captive Thumb Screws Yes (Side panels, GPU Holder, PSU Brace)
Miscellaneous
Dust Filter Top / Bottom
Net Weight 7.88kg
Gross Weight 9.11kg
Warranty 2 Year
Brands

Cooler Master
Case Warranty

SMPS Warranty

Country of Origin

China
